Product Description
We have deployed some of our best experienced experts to manufacture and export an exceptional range of Stability Chamber. In order to manufacture high quality chambers, our professionals employ advanced machines and utilize quality tested material procured from the authentic vendors. Owing to characteristics like unmatched performance, excellent insulation and easy operation, our Stability Chamber is used in diverse sectors such as medical, agricultural, industrial, research laboratories and metal treatment.
Features:
- Longer service life
- Durability
- Compact design
Specifications:
- Temperature + 10 C to 60 C
- Humidity (R.H.) 40% R.H. to 95% R.H.
- Humidity (R.H.) 40% R.H. to 95% R.H.
- ( Humidity ) Controller With an accuracy of +/-0.5 C & +/-3% R.H.
TECHNICAL SPECIFICATION :-
| Capacity |
90.0 ltrs. |
170.0ltrs. |
285.0ltrs. |
340.0ltrs. |
| Dimension |
Inner |
40 x 40 x 57 |
50 x 40 x 85 |
57 x 57 x 58 |
60 x 60 x 95 |
| Outer |
53 x 68 x 135 |
63 x 68 x 163 |
70 x 85 x 166 |
73 x 88 x 173 |
| Chamber |
Internal |
Stainless Steel 304 / 316L quality |
| External |
Mild Steel powder coated / Stainless steel Matt Finish |
| Temperature |
Range |
+ 10 C to 60 C |
| Accuracy |
+/-0.5 C fo set value for temp. / +/- 3% R.H. (humidity) |
| Uniformity |
+/- 0.5 C for temp +/- 3% Humidity |
| Water tank cartridge |
Reservoir |
4ltrs. |
4ltrs. |
9ltrs. |
9ltrs. |
| Boiler |
4ltrs. |
4ltrs. |
9ltrs. |
9ltrs. |
| Shelves |
2 |
2 |
3 |
3 |
| Colour |
Plate fin colour |
| Controller |
Digital Display Electronic Controllers |
| Compressor |
Hermetically sealed Brand New Kirloskar Compressor |
| Sensor |
Pt 100 for Dry and Wet Bulb capacitor type for Humidity. |
| Insulation |
Body |
Puf 50 mm / Glass Wool 65 mm |
| Door |
Thermo Cole |
| Inner Acrylic Door |
Inner Full Size Through Acrylic 8mm thick |
| Circulation |
1/12 Hp, 1440 R.P.M. Motorized blower from back |
| Heat up time |
30min. up to + 60 C. without load |
| Cool down time |
30min. up to + 60 C. without load |
| Steam Injection system |
I.S.I. Mark Kettel Heater |
Optional :-
- Imported Sensor 0 to 100% R. H. , Accuracy of +/- 2 C
- Computer Interface RS 485 / RS 232 interface for multiple / single
- communication port
- Safety devoice Thermostat or Energy Regulator. over heating or humidity soft alarm.
- Cyclic timer 0 to 24 hrs x 7 days cyclic ON / OFF timer for illuminating condition.
